Pinball Machine Control Board short-form kit

A kit to build the control board for Phil Prosser's Phenomenal Pinball Machine.

It includes the PCB and basically all that parts that mount on it. One of the few parts that isn't included is the optional expansion header.

See the link immediately below for a list of everything included in the kit.

The photo shows the assembled kit, including some mounting hardware, which is not included in the kit.

Cat No SC7659. Price: AUD $150.00 ¹

In stock:

yes (5 available). Estimated dispatch time: 1-3 days

Related to: Project: Phenomenal Pinball Machine, Part 1 (June 2026 [print issue])

Other items relevant to this project:

Pinball Machine Control PCB [08107261] ($25.00)
Pinball Machine Power Supply PCB [08107262] ($7.50)
Pinball Machine Player LED PCB [08107263] ($2.50)
Pinball Machine Score LED PCB [08107264] ($5.00)
Pinball Machine LED Output PCB [08107265] ($2.50)
Pinball Machine Bumper LED PCB [08107266] ($5.00)
Pinball Machine Cascade LED PCB [08107267] ($5.00)
Pinball Machine Switch Input PCB [08107268] ($2.50)
Pinball Machine General Input PCB [08107269] ($2.50)
Pinball Machine High Current Interface PCB [08107260] ($2.50)
Pinball Machine Rollover Interface PCB [08117261] ($2.50)
Pinball Machine Bumper Driver PCB [08117262] ($5.00)
5m of 10-way ribbon cable ($10.00)
Pinball Machine Power Supply short-form kit ($50.00)
Pinball Machine cable and connector set ($65.00)
Software and 3D printing files for Phil Prosser's Pinball Machine (Free)
Phil's Phenomenal Pinball Machine PCB patterns (PDF download) [08107260-9, 08117261-2] (Free)

Kit parts list

	1 × SPST momentary red tactile pushbutton switch
	1 × 16mm 10kΩ logarithmic single gang potentiometer (18t spline shaft)
	1 × Raspberry Pi Pico 2
	1 × Pinball Machine Control PCB [08107261]

Connectors

	1 × 40-pin male header (2.54mm pitch)
	2 × 20-pin female socket (2.54mm pitch)
	1 × 6-way vertical 5.08mm pluggable terminal block (pair)
	4 × 2-way vertical polarised header with matching plug & pins (2.54mm pitch)
	12 × 2-way vertical 5.08mm pluggable terminal block (pair)
	17 × 2×5-pin box header

Semiconductors

	12 × IPP80N06S4L-07 high-current N-channel Mosfet (TO-220)
	4 × 74HC165 8-bit parallel-to-serial latch IC (DIP-16)
	15 × 74HC595 8-bit serial latch IC (DIP-16)
	1 × LM384N 5W audio amplifier IC (DIP-14)
	64 × BC337-40 50V 0.8A NPN transistor (TO-92)
	1 × Red diffused 5mm high-brightness LED (30mA)
	64 × 1N4148 75V 200mA diode (DO-35)
	13 × 1N4004 400V 1A diode (DO-41)

Through-hole Capacitors

	2 × 2200µF 35V/50V electrolytic capacitor
	4 × 470µF 25V 105°C electrolytic (5mm pitch)
	1 × 47µF 16V sub-miniature electrolytic
	1 × 4.7µF 50V subminiature electrolytic (5mm pitch)
	33 × 100nF 50V X7R (5mm pitch)

Through-hole Resistors

	1 × 2.2kΩ ±1% ¼W
	145 × 1kΩ ±1% ¼W
	41 × 220Ω ±1% ¼W
	48 × 150Ω ±1% ¼W
	3 × 100Ω ±1% ¼W
	16 × 82Ω ±1% ¼W
	1 × 2.7Ω ±1% ¼W
